EX-6096
DIN-Rail Kit of Metal
The EX-6096 is a metal DIN-Rail Kit for various industrial products to be mounted on a DIN-Rail. The kit consists of a bracket without thread and two screws M3-4mm.
Applicable to EX-1185HMVS-WT, 1186HMVS, 1311VIS, 1315IS, 1344HMV, 1348HMV, 6006PoE
EX-6988
Plug-In power supply 12V/2A (5.5mm DC Jack)
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 12V/2A, 24W
Input: 100-240VDC / 50-60Hz, 0.6A
DC jack diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6972
HDR-30-24 power supply for various USB 3.2 Gen 1 4 Port DIN-Rail USB HUB
HDR-30-24 – DIN Rail Power Supply for EX-1177HMV/S, 1177HMVS-WT, 1182VIS, 1185HMVS, 1185HMVS-WT, 1194HMS, 1195HMS
Output DC 24V/1.5A/36W
Input: 85 ~ 264VAC
Ulta slim design with 17.5mm (1SU) width
Universal input 85~264VAC
Plastic case, step shape
Isolation class II
Pass LPS (limited power source)
DC output voltage adjustable
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection (working temperature: -30°~+70°C)
No load power consumption <0.3W
Assemble on industrial rail TS-35 / 7.5 or 15
Suitable for building automation and control of household appliance
Over voltage category II
LED indicator for power on
EX-SFP-0055
SFP Transceiver, LC, Duplex, Multimode, 550m, -40°C to +85°C
The EX-SFP-0055 SFP transceiver is a high-performance, cost effective module with a data rate of 1.25 Gbps and a transmission distance of up to 550 m with multimode fiber. The transceiver consists of three parts: a VCSEL laser transmitter, a PIN photodiode integrated with a transimpedance preamplifier (TIA), and an MCU control unit. All modules meet laser safety class I requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
Data rate of 1.25Gbps
850nm VCSEL laser and PIN photodetector
Compliant with SFP MSA and SFF-8472 with duplex LC socket
Digital diagnostic monitoring, internal or external calibration
550m transmission with 50/125μm multimode fiber
330m transmission with 62.5/125μm multimode fiber
Extended operating temperature range from -40°C to +85°C
Other SFP modules available on request
EX-6091
Mounting kit for 19" components, M6, set of 4
The 19" mounting kit EX-6091 is used to attach front panels, distribution fields or other components on the frame, slide mounts or depth members with square cut-outs.
For standard-compliant GND/earthing, use an earthing cage nut and a nomel washer at at least one fixing point
Delivery contents:4x pan-head screw M6 x 16, galvanised, 4x plastic washer, black, 4x cage nut M6, galvanised.
EX-6990
Power Supply 12V/5A (5.5mm DC Jack)
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 12V/5A, 60W
Input: 100-240VDC / 50-60Hz, 1.6A
DC jack diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6991
Plug-In power supply 5V/2A (DC Jack 5.5mm)
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 5V/2A, 10W
Input: 100-240VDC / 50-60Hz, 0.5A
Diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6993
Plug-In power supply 5V/2A (DC Jack 3.5mm/1.35mm)
Plug-In power supply for EXSYS product EX-1200
Output: 5V/2A, 10W
Input 110V-240V 50/60Hz, 0.3A
DC jack diameter: 3.5mm outside / 1.35mm inside
Positive pole inside
EX-6099
DIN-Rail Kit of Metal with thread
The EX-DIN-Rail it’s a Kit of Metal with thread for different industrial products for fix to DIN-Rail. The Kit include two metal bracket.
Applicable to EX-1166HMV, EX-1178, EX-1178S, EX-1178-W, EX-1188HMS, EX-1188HMS-3, EX-1189HMVS-3, EX-1189HMVS-3W, EX-1517HMVS, EX-1332HMV, EX-1333V, EX-1333VIS, EX-1334HMV-2, EX-1335HMV, EX-6031, EX-6031PoE, EX-6032, EX-6034, EX-6051
EX-10000
ExpressCard Kit 34/54mm for more stability
The EX-10000 ExpressCard Kit expand the ExpressCard in the breadthways from 34mm to 54mm. Thereby the ExpressCard have then a lateral stability in your ExpressCard Slot from the Notebook. In this case the connected card don t lose anymore the contact to the connector inside from the Notebook. The installation are easy and can use for all ExpressCard with a breadth of 34mm.
Expand the ExpressCard slot from 34mm to 54mm breadth
Plastic case with a metal clip
Packaging contents:EX-10000, Manual
EX-3465
1-to-4 Switch from one SATA 3 to four SATA 3 HDD or SSD
The EX-3465 1-to-4 SATA 3 Switch is designed to provide a high performance link between a single SATA 3 host port and 4 SATA 3 devices ports. It connects the host upstream port to one of the 4 downstream SATA 3 hard drive or SSD drive (one device at the same time). It is done by simply pressing the push button switch. It only allowed the selected device to be powered and cut off the powers of the other unselected devices. This will reduce the power consumption and make sure those devices are true off line to prevent from any accidental erasing data by virus or application software. The EX-3465 provides a keylock switch to prevent from any unauthorized changing the settings. It helps home of school users to manage the devices easily.
!! Attention !!The switching of hard disk during the operation, work only when the mainboard include Chipset what support “Hot Plug and Play” for example Silicon Image 3132. With our controller EX-3516 or EX-3501 the SATA switch works fine.
Switch with 1 Upstream to 4 Downstream SATA 3 or SAS ports
Support hard drives up to 6TB
3.5 or 5.25-inch Bay Form Factor, Easy to Fit in Normal PC Systems
Built-in High Speed SATA Signal Switch, save the Current Settings by Built-in EEPROM
Keylock to Prevent from Unauthorized Changing
Provides LEDs to Indicate the Active Drive
Completed cable set fort 4 SATA 3 drives will be included
Chipset: Silicon Image SIL-3726
Packaging contents:EX-3465, 4x SATA cable set, 5 1/4" frame, Manual
EX-6995
Power Supply 12V/3A, DC Jack diameter 5.5mm/2.1mm
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 12V/3A, 36W
Input: 100-240VDC / 50-60Hz, 1.0A
DC jack diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6994
Power Supply for EX-1031/1032/1041/1042
Power Supply for Expansion Box EX-1031, EX-1032, EX-1041, EX-1042
Input: 110V to 240V, 50/60Hz
Output: +12V, +5V, +3.3V
ATX Main Power Connector 24 Pin = 20 Pin + 4 Pin
Processor Power Connector 4 Pin
Serial ATA Power Connector 15 Pin
Peripheral Power Connector 4 Pin
Floppy Drive Power Connector 4 Pin
EX-3455
Backup SATA 2 System Hardware RAID 0 and 1
The EX-3455 Hardware RAID controller is designed to easily upgrade their existing or new system with a RAID 1 or 0. The installation it’s very easy. Both hard disk and the mainboard are connected to the EX-3455. In a existing operating system, the data from the hard disk 0 are copy in the background automatically to the hard disk 1. In this time you can works normal. With a new installation from a operating system, the data are copy in the same time without loss of speed to the two hard drives. The EX-3455 can install in a 3.5 or 5.25-inch front bay or in one PCI-Express Slot. With the LowProfile bracket the EX-3455 you can use also in a small computer case with a maximal high of 8cm. The EX-3455 don't need driver or software and can use for all Operating system.
1-to-2 SATA 2 hardware RAID 0/1 for two SATA 2 hard drives
Supports RAID 0, 1, LARGE and EZ-RAID 1 modes and set by DIP switches
RAID 1 supports Auto Re-build in Background
3.5 or 5.25-inch Bay Form Factor, easy to fit in normal or small PC systems
Supports over 2TB hard drives
LEDs to indicate the RAID and Drive status
Completed set of cables (SATA 2 and Power), incl. standard and low profile bracket
For all Operating System
Packaging contents:EX-3455, 3x SATA2/3 cables, 1x power cable, 3 1/2" and 5 1/4" frames, standard and Low Profile bracket, manual
EX-6997
Power Supply 5V/4A DC Jack 5.5mm for EX-1178 and EX-1178S
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 5V/4A, 20W
Input: 100-240VDC / 50-60Hz, 0.5A
Diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6950
Power Supply for EX-1163HM and EX-1163HMVS-WT
MDR-20-24 – 20W Single Industrie DIN Rail Power Supply
Output: 24V/24W/1A
Input: 85 ~ 264VAC, 0.35A
Universal AC input/Full range
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
NEC class 2 / LPS compliant
LED indicator for power on
No load power consumption<0.75W
100% full load burn-in test
EX-6955
MDR-40-24 Power Supply for EX-1177HMV/S and EX-1187HMVS
MDR-40-24 – 40W Industrie DIN Rail Power Supply (für EX-1177HMV/S und EX-1187HMVS)
Output: 24V/40W/1.7A
Input: 85 ~ 264VAC, 0.7A
Universal AC input/Full range
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
NEC class 2 / LPS compliant (12V,24V,48V only)
LED indicator for power on
DC OK relay contact
No load power consumption<0.75W
100% full load burn-in test
EX-1111
10x USB 3.2 Gen 1 / 2.0 Protection Cap for USB Type A-Connector
The EX-1111 can be used to protect unused USB 3.0 or 2.0 A-sockets against dirt or other influences. The EX-1111 is pushed into the A sockets and ensure that no foreign objects or dust can penetrate. If necessary, the protective caps are simply pulled off again.
Features:
Protection Cap for USB 3.0 or 2.0 A-Female connector
Easy to install and remove
Protects against dust, dirt and water splashes
Specifications:
Hardware system: For all USB 3.0 or 2.0 A-female connector
Material: hard plastic
Operating Temperature : 320 up to 1310 Fahrenheit
Storage Temperature: -400 up to 1670 Fahrenheit
Rel. Humidity: 5% to 95%
Weight: 100 g
Packaging contents:10x EX-1111
EX-6989
Plug-In power supply 12V/3A (5.5mm DC Jack)
Power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 12V/3A, 36W
Input: 100-240VDC / 50-60Hz, 1.0A
DC jack diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
EX-6998
Plug-In power supply 12V/1A DC Jack 5.5mm/2.1mm Diameter
Plug-In power supply unit with DC jack for powering various devices. Suitable for several EXSYS products.
Output: 12V/1A, 12W
Input: 100-240VDC / 50-60Hz, 0.3A
DC jack diameter: 5.5mm outside / 2.1mm inside
Positive pole inside
SFP-1GSXLC
1-Port Gigabit Ethernet SFP module, LC duplex, Multi-mode
The SFP-1G Series 1-port Gigabit Ethernet SFP modules are available as optional accessories for a wide range of Moxa Ethernet switches.
Digital Diagnostic Monitor Function
IEEE 802.3z compliant
Differential LVPECL inputs and outputs
TTL signal detect indicator
Hot pluggable LC duplex connector
Class 1 laser product, complies with EN 60825-1
EX-6945
120W DIN Rail Power Supply 48V/2.5A - Meanwell
Features
Universal AC input 88-264Vac
Built-in active PFC function
Can be installed on DIN Rail TS-35/7.5/15
150% peak load capability
Operating temperature -25°C to +70°C
LED Indication for DC OK
Dimension 40 x 125.2x 113.5mm (W x H x D)
3 years warranty
Manufacturer: MEAN WELL
SFP-1GLXLC
1-Port Gigabit Ethernet SFP module, LC duplex, Single-mode
The SFP-1G Series 1-port Gigabit Ethernet SFP modules are available as optional accessories for a wide range of Moxa Ethernet switches.
Digital Diagnostic Monitor Function
IEEE 802.3z compliant
Differential LVPECL inputs and outputs
TTL signal detect indicator
Hot pluggable LC duplex connector
Class 1 laser product, complies with EN 60825-1
EX-6097
DIN-Rail Kit of Metal
The EX-6097 is a DIN rail kit for rackmount mounting of EXSYS products, without threads. The kit consists of two brackets and four screws.
Applicable to EX-1163HM, 1177HMV, 1177HMVS, 1177HMVS-WT, 1185HMVS, 1187HMVS, 1316HMVS, 1332HMV-RH, 6030, 6300MM, 6300SM
