The Gigabit Ethernet PoE+ Splitter EX-60326 splits the signal of a PoE supplier (PSE) into data and power supply and outputs both signals separately. This allows non-PoE-capable Ethernet end devices (IP cameras, WLAN access points...) to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE++ standard IEEE 802.3bt and provides a voltage of 12VDC with a power of max. 36W at the terminal block for feeding the end device. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a wide range of applications even in harsh environments. Included in delivery is a DIN rack kit (pre-assembled) and a wall mounting bracket. Separates data and power supply of a PoE signal to power non-PoE capable Ethernet end devices Reduces system wiring, improves system stability/security, and reduces maintenance costs Voltage output via terminal block: 12VDC max. 36W Fully IEEE 802.3af/at/bt Power Over Ethernet (PoE) compliant 10/100/1000Base-T Gigabit Ethernet Plug and play, no configuration and installation required LED status indicators for power supply and PoE Rugged, compact metal housing, IP40 Includes DIN-Rail Kit and wall mounting bracket Extended operating temperature range from -40°C to +80°C Packaging contents:EX-60326, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual

The Gigabit Ethernet PoE+ Splitter EX-60325 splits the signal of a PoE supplier (PSE) into data and power supply and outputs both signals separately. This allows non-PoE-capable Ethernet end devices (IP cameras, WLAN access points...) to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE+ standard IEEE 802.3at and provides a voltage of 12VDC with a power of max. 20W at the terminal block for feeding the end device. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a wide range of applications even in harsh environments. Included in delivery is a DIN rack kit (pre-assembled) and a wall mounting bracket. Separates data and power supply of a PoE signal to power non-PoE capable Ethernet end devices Reduces system wiring, improves system stability/security, and reduces maintenance costs Voltage output via terminal block: 12VDC max. 20W Fully IEEE 802.3af/at Power Over Ethernet (PoE) compliant 10/100/1000Base-T Gigabit Ethernet Plug and play, no configuration and installation required LED status indicators for power supply and PoE Rugged, compact metal housing, IP40 Includes DIN-Rail Kit and wall mounting bracket Extended operating temperature range from -40°C to +80°C Packaging contents:EX-60325, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual

The Ethernet PoE+ Splitter EX-60320 splits the signal of a PoE supplier (PSE) into data and power supply and outputs both signals separately. This allows non-PoE-capable Ethernet end devices (IP cameras, WLAN access points...) to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE+ standard IEEE 802.3at and provides a voltage of 12VDC at the DC connector with a power of max. 21W to feed the end device. The compact design as adapter cable offers extremely flexible application possibilities. Separates data and power supply of a PoE signal to power non-PoE capable Ethernet end devices Reduces system wiring, improves system stability/security, and reduces maintenance costs Voltage output at DC connector: 12VDC max. 21W Fully IEEE 802.3af/at Power Over Ethernet (PoE) compliant 10/100Base-TX Ethernet Plug and play, no configuration and installation required LED status indicators for PoE power supply Compact design as a cable adapter ABS and flame retardant polycarbonate plastic enclosure 2 KV insulation protection, protection against short circuit, overcurrent and overtemperature Packaging contents:EX-60320, Manual

The Gigabit Ethernet PoE+ Splitter EX-60321 splits the signal of a PoE supplier (PSE) into data and power supply and outputs both signals separately. This allows non-PoE-capable Ethernet end devices (IP cameras, WLAN access points...) to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE+ standard IEEE 802.3at and provides a voltage of 24VDC with a power of max. 30W at the terminal block for feeding the end device. Thanks to the robust metal housing, it is suitable for a wide range of applications even in harsh environments. A DIN-Rail Kit (pre-assembled) is included in the delivery. Separates data and power supply of a PoE signal to power non-PoE capable Ethernet end devices Reduces system wiring, improves system stability/security, and reduces maintenance costs Voltage output at DC connector: 24VDC max. 30W (PD) Fully IEEE 802.3af/at/bt Power Over Ethernet (PoE) compliant 10/100/1000Base-TX Ethernet Plug and play, no configuration and installation required LED status indicators for power supply and PoE Rugged, compact metal housing, IP40 Includes DIN-Rail Kit Packaging contents:EX-60321, Manual

The Gigabit Ethernet PoE++ splitter EX-60327 splits the signal from a PoE server (PSE) into data and power supply and outputs both signals separately. This means that non-PoE-capable Ethernet end devices (IP cameras, WLAN access points, etc.) can also be connected to a PoE switch or other PSE and use its power supply. It complies with the PoE++ standard IEEE 802.3bt. The voltage at the terminal block for supplying the end device can be set individually between 3VDC and 36VDC. The maximum output power is 50W at max. 10A. The EX-60327's robust metal case and extended operating temperature range of -40°C to 75°C make it suitable for a wide range of applications, even in harsh environments. Supplied with a pre-mounted DIN-Rail kit and a wall mounting bracket. Separates data and power from a PoE signal to supply non-PoE-capable Ethernet end devices Reduces system cabling, improves system stability/security and reduces maintenance costs Output voltage adjustable at the terminal block: 3-36VDC max. 50W/10A Fully compliant with IEEE 802.3af/at/bt Power over Ethernet (PoE) 10/100/1000Base-T Gigabit Ethernet Plug and play, no configuration or installation required Digital real-time display of output voltage and current Rugged, compact metal housing, IP40 Includes DIN-Rail kit and wall mounting bracket Extended operating temperature range from -40°C to +75°C Scope of delivery:EX-60327, DIN rail kit (pre-assembled), wall mounting kit, manual
