EX-48023
mini PCIe 2S Serial RS-232/1P Parallel, Multi I/O card
The EX-41150 PCI Multi I/O adapter provides s high performance 16C550-type UART compatible RS-232 serial ports and one Parallel Centronics EPP/ECP port. It is designed for PC, thin client or server to provide instant COM and LPT port expansion via the PCI Bus. The card is fully PCI Plug-and-Play compatible and there are no IRQ and I/O address configuration problems. It additionally provides +5V and +12V via the pin 9 at the male connector for a POS System (Power over System).
Interface: Serial RS-232 V.24 / Parallel EPP/ECP
FIFO Buffer: 16C550 with 16Byte
I/O addresses and Interrupt: Setting from the System BIOS with IRQ Sharing
Data Bits: 5, 6, 7, 8 / Stop Bits: 1, 1.5, 2 / Parity: none, even, odd, space, mark
Signal: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Support Mother-Board with 5V and 3.3V
Windows WHQL certified
Chipset: MosChip MCS9835CV
EX-48024
4S Serial RS-232 mini PCIe card (MosChip chipset)
The EX-48024 Mini PCI-Express adapter provides four high performance 16C550-type UART compatible RS-232 serial ports. It is designed for Computer system or Boards to provide instant COM port expansion via the Mini PCI-Express Bus. The card is fully PCI Plug-and-Play compatible and there are no IRQ and I/O address configuration problems.
Interface: Serial RS-232 V.24
FIFO Buffer: 16C550 with 16Byte
I/O addresses and Interrupt: Setting from the System BIOS with IRQ Sharing
Data Bits: 5, 6, 7, 8 / Stop Bits: 1, 1.5, 2 / Parity: none, even, odd, space, mark
Signal: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Chipset: MosChip MCS9904CV
EX-3605
M.2 NGFF to SATA converter with 2.a5-inch metal frame
The EX-3605 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3605 need a SATA connector from the mainboard or from a SATA controller. You can use following M.2 NGFF module: 2280, 2260, 2242 and 2230. The module with B-key and also B+M-key will be supported.
Convert M.2 NGFF SATA SSD to standard 2.5” SATA Form Factor
M.2 NGFF type 2280-xx-B connector on board
Supports M.2 NGFF type 2280, 2260, 2242 and 2230 plated-hole
100% compatible with 2.5-inch SATA drive mechanical specification
22 pin SATA connector (signal and power)
M.2 NGFF SATA SSD can be the primary bootable device containing the OS
Transparent to the operating system and don’t need driver
With the product we delivery 4 screw for fix the 2.5” frame in the computer case and also one screw for fix the M.2 NGFF module
Packaging contents:EX-3605, 4x screw for fix the 2.5” frame, 1x screw for fix the M.2 modules, Manual
EX-3650
PCIe (x4) controller to M.2 NGFF module incl. Low Profile bracket
With the EX-3650 controller you can add in your Computersystem a PCIe based (NVMe + AHCI) M.2 NGFF slot. You can use following M.2 NGFF module: 2280, 2260 and 2242. The EX-3650 need a PCI-Express x4 slot.
Convert M.2 NGFF PCIe SSD to work in main board PCIe x4 bus slot
Supports M.2 NGFF type 2280, 2260 and 2242 plated-hole with M-Key or B+M-Key based on PCIe
Supports NVM Express (NVMe)
Can be installed as boot drive
Transparent to the operating system and don’t need driver
Maximum high of 1.5mm component height on the top and bottom side
Supports dual-sided SSD module
Supports PCIe 1.0, 2.0 and 3.0 mainboard
Pin header on board for drive LED connection
Packaging contents:EX-3650, 1x screw for fix M.2 modules, Low Profile bracket, Manual
EX-3655
PCIe (x4) controller for two M.2 NGFF Module incl. Low Profile bracket
With the EX-3655 controller you can expand the computer with two M.2 NGFF slot. The modules M.2 NGFF 22110, 2280, 2260 and 2242 can be used. Modules with B-Key as well as B+M Key are supported. The EX-3655 requires a PCI-Express x4 slot. With the EX-3655 a low profile bracket for narrow computer cases up to 8 cm height is included.
PCIe (x4) board for two M.2 NGFF SSD drives
Supports M.2 NGFF type 22110, 2280, 2260 and 2242 plated-hole
Power from the PCIe bus or from the 4 pin power connector
Can be fitted on both sides
Supports PCIe 1.0, 2.0 and 3.0 mainboard
Pin header on board for drive LED connection
Packaging contents:EX-3655, 1x screw for fix M.2 modules, Low Profile bracket, Manual
EX-3660
PCIe (x4) controller for two SATA M.2 NGFF and one PCIe M.2 NGFF module
With the EX-3660 controller you can equip the computer with two SATA M.2 NGFF modules as well as one PCIe (NVMe + AHCI) M.2 NGFF module. The modules M.2 NGFF 22110, 2280, 2260 and 2242 can be used. Modules with B-Key as well as B+M Key are supported. The EX-3660 requires a PCI-Express x4 slot. A low profile bracket for narrow computer cases up to 8 cm height is included with the EX-3660.
Attention:For the two SATA M.2 NGFF module you must use two SATA cable what is connect to the mainboard.
PCIe (x4) board for two SATA M.2 NGFF and one PCI M.2 NGFF SSD
Supports M.2 NGFF type 22110, 2280, 2260 and 2242 plated-hole
Power from the PCIe bus or from the 4 pin power connector
Supports dual-sided SSD module 1.5mm component height on the top and bottom side
Supports PCIe 1.0, 2.0 and 3.0 mainboard
Supports Native Command Queuing (NCQ)
Packaging contents:EX-3660, 3x screw for fix M.2 modules, Low Profile bracket, Manual
EX-3670
PCIe (x4) RAID 0/1 controller with two M.2 NGFF slots and SATA ports
With the EX-3670 RAID 0/1 controller you can expand the computer with two SATA based M.2 NGFF modules and two SATA connectors. The modules M.2 NGFF 22110, 2280, 2260 and 2242 can be used. Modules with B-Key as well as B+M Key are supported. The EX-3670 requires a PCI-Express x4 slot.
Hyperduo function:The Hyper Duo function supports an M.2 NGFF module in combination with an HDD. Thus, the advantages of both data carriers can be utilized. With the high capacity of the HDD and the speed of the SSD, you achieve a perfect unity.
PCIe (x4) RAID 0/1 controller for two M.2 NGFF and SATA ports
Supports RAID 0 / 1 and 10
Supports M.2 NGFF type 22110, 2280, 2260 and 2242 plated-hole
Supports dual-sided SSD module 1.5mm component height
Supports SATA 1 to 3 for HDD and M.2 NFGG SSD
Supports PCIe 1.0, 2.0 and 3.0 mainboard
Supports Hyper-Duo-Function virtual disk (see in the description)
Supports Native Command Queuing (NCQ)
Power from the PCIe bus or from the 4 pin power connector
Can be installed as boot drive
Packaging contents:EX-3670, 2x screw to fix M.2 modules, Low Profile bracket, Driver CD, Manual
EX-48011
USB 3.2 Gen 2x1 mini PCIe board with 1x C-port (ASMedia)
The EX-48011 USB 3.2 Gen 2x1 mini PCIe board offer you one external Super-Speed+ USB 3.2 Gen 2x1 port with C-female connector. The port reached a data transfer of up to 10Gigabit per second. The EX-48011 it’s design for connect one more USB 1.1, 2.0, 3.2 Gen 1 or 3.2 Gen2 peripheral device to your mainboard, laptop or system with Mini PCIe slot. It supports USB 1.1 Low-Speed (1.5Mbps), Full-Speed (12Mpbs), USB 2.0 High-Speed (480Mbps), USB 3.2 Gen 1 Super-Speed (5Gbps) and USB 3.2 Gen 2x1 Super-Speed+ (10Gbps). It is an ideal technology for external storage devices, digital cameras, webcams, scanners and much more.
USB 3.2 Gen 2x1 Mini PCIe card with one C-female connector
Compliant with USB 3.2 Rev. 1 and Intel xHCI Rev. 1.0 specification
Fully PCI Express Gen2 Specification Compliant
Compatible with USB Attached SCSI Protocol Rev. 1.0
Supports “Hot Swapping” and “Plug-and-Play”
Supports up to 127 USB devices (USB1.1, USB2.0, USB3.0, USB3.1 and USB 3.2)
Packaging contents:EX-48011, Power cable, Driver CD, Manual
EX-3671
USB 3.2 Gen 2x1 to M2 & mSATA Enclosure with Micro-B connector
The EX-3671 converter is an external enclosure to replace a 2.5" hard drive or SDD. An M.2 SSD module 2280, 2260, 2242 and 2230 as well as an mSATA module with half size or full size can be used in the enclosure. If you occupy both slots only the M.2 SSD module can be used. The EX-3671 is connected to the computer via a USB port.
Ports with Micro-B USB 3.2 Gen 2x1 with 10Gbps
Converts 1x Half and Full Size mSATA SSD and M.2 NGFF SSD to USB 3.2 Gen 2x1 2.5-inch enclosure with 9.5mm height
Build in ASM1351 USB 3.2 high performance processor
Supports M.2 NGFF 2280, 2260, 2242 and 2230 Type Form Factor B-Key and B+M-Key and mSATA Half Size and Full Size
Compliant with Universal Serial Bus 3.1 specification revision 1.0
Power Supply over the USB 3.2 Micro-B 5V Bus
3A maximum output current
Short circuit protection as thermal shutdown protection
LED display for power and active status
Included the mounting screw for mSATA and M.2
Packaging contents:EX-3671, Screw for fix M.2 and mSATA modules, USB cable 35 cm, Manual
EX-3672
USB 3.2 Gen 2x1 to M.2 & mSATA SSD Enclosure (2.5-inch) with USB cable C-male to A-male connector
The EX-3672 converter is an external enclosure to replace a 2.5" hard disk or SDD. An M.2 SSD module 2280, 2260, 2242 and 2230 as well as an mSATA module with half size or full size can be used in the enclosure. If you occupy both slots only the M.2 SSD module can be used. The EX-3672 is connected to the computer via a USB port.
Ports with C-Type USB 3.2 Gen 2x1 with 10Gbps
Converts 1x Half and Full Size mSATA SSD and M.2 NGFF SSD to USB 3.2 Gen 2x1 2.5-inch enclosure with 9.5mm height
Build in ASM1351 USB 3.2 high performance processor
Support M.2 NGFF 2280, 2260, 2242 and 2230 Type Form Factor B-Key and B+M-Key and mSATA Half Size and Full Size
Compliant with Universal Serial Bus 3.1 specification revision 1.0
Power supply 5V via the USB 3.2 C socket
3A maximum output current
Short circuit protection as thermal shutdown protection
LED display for power and active status
Packaging contents:EX-3672, Screw to fix M.2 and mSATA modules, USB cable 35 cm, Manual
EX-3673
USB 3.2 Gen 2x1 to M.2 & mSATA card with B-female connector
The EX-3673 converter is a board to replace a 2.5 inch hard disk or SDD. Two M.2 SSD modules 2280, 2260, 2242 and 2230 type with B-Key or B+M-Key as well as two mSATA modules with Half Size or Full Size can be used on the board. The EX-3673 is connected to the computer via a USB port.
Connector with B-female with USB 3.2 Gen 2x1 with 10Gbps
Converts 2x Half and Full Size mSATA SSD and 2x M.2 NGFF SSD to USB 3.2 Gen 2x1
Build in ASM1351R USB 3.2 high performance processor
Supports M.2 NGFF 2280, 2260, 2242 and 2230 Type Form Factor B-Key and B+M-Key and mSATA Half Size and Full Size
Compliant with Universal Serial Bus 3.1 specification revision 1.0
Power Supply over the USB 3.2 Micro-B 5V Bus
3A maximum output current
Short circuit protection as thermal shutdown protection
Packaging contents:EX-3673, Screw to fix M.2 and mSATA modules, Manual
EX-3674
USB 3.2 Gen 2x1 and SATA 3 to M.2 & mSATA SSD
An M.2 SSD module 2280, 2260, 2242 and 2230 type with B-Key or B+M-Key as well as an mSATA module with Half Size or Full Size can be used on the EX-3674. It is connected to the computer via a USB 3.2 or SATA 3 port.
Connector with B-female with USB 3.2 Gen 2x1 with 10Gbps or SATA 3
Converts 1x Half Size and Full Size mSATA SSD and M.2 NGFF SSD to USB 3.2 Gen 2x1
Supports M.2 NGFF 2280, 2260, 2242 and 2230 Type Form Factor B-Key and B+M-Key and mSATA Half Size and Full Size
Compliant with Universal Serial Bus 3.1 specification revision 1.0
Power Supply over the USB 3.2 B-female 5V connector
3A maximum output current
LED display for M.2/mSATA SSD for power as if the module are active
Packaging contents:EX-3674, Screw to fix M.2 and mSATA modules, Manual
EX-3675
USB 3.2 Gen 1 Micro-B für M.2 or mSATA SSD & SATA
USB 3.2 Micro-B for M.2 or mSATA SSD & SATA Adapter (M.2 or mSATA SSD alternative)
Build in ASM1351 USB3.1high performance processor
Build in SATA 22pin Female connector
Build in Mini PCI-e Female connector
Build in M.2 NGFF Female connector
PWM synchronous buck converter Power IC
3A maximum output current
Short circuit protection
Thermal shutdown protection
ESD HBM (Human Body Mode)/2KV
D1 Red LED on indicates SSD Power ready
D2 Red LED Blinking indicates SSD active status
Notice:M.2 SSD or mSATA SSD, only one can work, M.2 SSD would be priority
EX-3680
USB 3.2 Gen 2x1 to mSATA RAID 0/1 with 2.5-inch metal frame (7mm)
The EX-3680 converter can be used as a replacement for a 2.5" hard disk or SDD. For the connection of the EX-3680 a USB 3.0 port on the mainboard or a USB 3.0 controller is required. Half Size as well as Full Size modules can be used.
USB 3.2 Gen 2x1 to 6Gbps SATA 3 Hardware RAID Controller
Converts 2x Full Size mSATA SSD to USB 3.2 Gen 2x1 2.5-inch case with 7 mm height
Supports with Jumper RAID 0, 1, JaOBD
Supports two SATA 2 and SATA 3 (6Gbps) mSATA SSD
Supports ATA/ATAPI Packet Command Set
Supports ATA/ATAPI LBA 48 Addressing Mode
100% compatible with 2.5-inch SATA drive mechanical specification
Supports USB 3.2, 3.0 and 2.0 mainboard
Compliant with Universal Serial Bus 3.1 specification Rev. 1.0
Power from the USB 3.2 Micro-B 5V Bus
Transparent to the operating system, no driver needed
Packaging contents:EX-3680, 4x screws for mounting the 2.5" frame, manual
EX-3681
USB 3.2 Gen 1 to mSATA RAID 0/1 with 2.5-inch metal frame (7mm)
The EX-3681 converter can be used as a replacement for a 2.5" hard disk or SDD. For the connection of the EX-3681 a USB 3.0 port on the mainboard or a USB 3.0 controller is required. Half size as well as full size modules can be used. The "Write Protect" switch can be used to protect data from being overwritten. The EX-3681 comes with a standard and low profile bracket and can also be installed vertically in the PC.
USB 3.2 Gen 1 to 6Gbps SATA 3 Hardware RAID Controller
Converts 1x Full Size mSATA SSD to USB 3.0 - 2.5-inch case with 7mm height
Supports one SATA 2 and SATA 3 (6Gbps) mSATA SSD
100% compatible with 2.5-inch SATA drive mechanical specification
Supports USB 3.0 and 2.0 mainboard
Supports ATA/ATAPI Packet Command Set
Supports ATA/ATAPI LBA 48 Addressing Mode
Compliant with Universal Serial Bus 3.0 specification Rev. 1.0
Write Protect switch can prevent the data writing to mSATA SSD
Power from the USB 3.0 Micro-B 5V Bus
Transparent to the operating system, no driver needed
Packaging contents:EX-3681, 4x screws for mounting the 2.5" frame, Low Profile bracket, manual
EX-3682
SATA3 to mSATA with 2.5-inch metal frame (9.5mm)
The EX-3682 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3682 need a SATA 3 connector from the mainboard or from a SATA 3 controller. You can use the Half Size and Full Size module.
Convert 1x Full Size mSATA SSD to 2.5-inch case with 9.5mm height
Support one SATA 1, SATA 2 and SATA 3 (6Gbps)
100% compatible with 2.5-inch SATA drive mechanical specification
22 pin SATA (Signals and Power) male connector on board
The mSATA SSD can be the primary bootable device containing the OS and application
Transparent to the operating system and don’t need driver
For fix the 2.5” frame in the computer case we include 4 screws and for the mSATA module we include 2 screws
Packaging contents:EX-3682, 4x screws for mounting the 2.5" frame, 2x screw for mSATA module, manual
EX-3683
SATA3 to 2x mSATA SSD (RAID) with 2.5-inch metal frame (9.5mm)
The EX-3683 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3683 need a SATA 3connector from the mainboard or from a SATA 3 controller. You can use the mSATA module: Half Size and Full Size. The EX-3683 support RAID 0 / 1 and JBOD.
Built-in ASM1092R high performance processor
Supports Half Size or Full Size module
100% compatible with 2.5-inch SATA drive mechanical specification
Support RAID mode: RAID 0 (fast) / RAID 1 (safe) and JBOD (volume)
RAID mode switch by hardware strapping or GUI controller
22 pin SATA connector (signal and power)
Support SATA 3 Revision 3.2
Transparent to the operating system and don’t need driver
Green LED indicate SATA 3 host active, red LED indicate M.2 NGFF SSD error
Packaging contents:EX-3683, 4x screws for mounting the 2.5" frame, manual
EX-3684
SATA3 to 2x mSATA SSD & SATA 2 with 2.5-inch metal frame, RAID 0/1
The EX-3684 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3684 need a SATA 3 connector from the mainboard or from a SATA 3 controller. You can use the mSATA module: Half Size and Full Size. In the same time it’s possible to connect two other hard drive or SSD to the two SATA 2 ports. The EX-3684 support RAID 0 / 1 and JBOD. Included it’s a bracket for install vertical in the PC.
Built-in ASM1092R high performance processor
Supports Half Size or Full Size module
100% compatible with 2.5-inch SATA drive mechanical specification
Support RAID mode: RAID 0 (fast) / RAID 1 (safe) and JBOD (volume)
RAID mode switch by hardware strapping or GUI controller
22 pin SATA connector (signal and power)
Support SATA 3 Revision 3.2
Transparent to the operating system and don’t need driver
Additional it’s include a bracket for install on the backside from the PC
Packaging contents:EX-3684, 4x screws for mounting the 2.5" frame, 1x bracket, manual
EX-3606
SATA 3 to 2x M.2 SSD Enclosure RAID, 2.5inch (9.5mm)
The EX-3606 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3606 need a SATA 3 connector from the mainboard or from a SATA 3 controller. You can use following M.2 NGFF module: 2280, 2260, 2242 and 2230 and support the module with B-key and also B+M-key. The EX-3606 support RAID 0 / 1 and JBOD.
Built-in ASM1092R high performance processor
Supports M.2 NGFF type 2280, 2260, 2242 and 2230 plated-hole
100% compatible with 2.5-inch SATA drive mechanical specification
Support RAID mode: RAID 0 (fast) / RAID 1 (safe) and JBOD (volume)
RAID mode switch by hardware strapping or GUI controller
22 pin SATA connector (signal and power)
Support SATA 3 Revision 3.2
Transparent to the operating system and don’t need driver
Green LED indicate SATA 3 host active, red LED indicate M.2 NGFF SSD error
Packaging contents:EX-3606, 4x screw for fix the 2.5” frame, Assembly Guide
EX-3607
SATA 3 to 2x M.2 SSD & SATA 2 (RAID) with 2.5-inch metal frame (9.5mm)
The EX-3607 converter can used for a replacement of a 2.5-inch hard drive or SSD. For connect the EX-3606 need a SATA 3 connector from the mainboard or from a SATA 3 controller. You can use following M.2 NGFF module: 2280, 2260, 2242 and 2230 and support the module with B-key. Additional can connect SATA 2 devices. The EX-3607 support RAID 0/1 and JBOD. Included it’s a bracket for install vertical in the PC.
Built-in ASM1092R high performance processor
Supports M.2 NGFF type 2280, 2260, 2242 and 2230 plated-hole
Can connect simultaneously two other SATA 2 devices
100% compatible with 2.5-inch SATA drive mechanical specification
Support RAID mode: RAID 0 (fast) / RAID 1 (safe) and JBOD (volume)
RAID mode switch by hardware strapping or GUI controller
22 pin SATA connector (signal and power)
Support SATA 3 Revision 3.2
Transparent to the operating system and don’t need driver
Additional it’s include a bracket for install on the backside from the PC
Packaging contents:EX-3607, 4x screw for fix the 2.5” frame, Assembly Guide
EX-3608
SATA 3 to 2x M.2 & mSATA (RAID) with 3.5-inch metal frame or PCIe slot
The EX-3608 converter can used for a replacement of a 3.5-inch hard drive or SSD. For connect the EX-3608 need a SATA 3 connector from the mainboard or from a SATA 3 controller. You can use two M.2 NGFF module 2280, 2260, 2242 and 2230 with B-key as two mSATA module with Half Size or Full Size. The EX-3608 support RAID 0/1 and JBOD. Included it’s a bracket for install vertical in the PC.
Built-in ASM1092R high performance processor
Supports M.2 NGFF type 2280, 2260, 2242 and 2230 plated-hole
Can connect simultaneously two other SATA 2 devices
100% compatible with 2.5-inch SATA drive mechanical specification
Support RAID mode: RAID 0 (fast) / RAID 1 (safe) and JBOD (volume)
RAID mode switch by hardware strapping or GUI controller
22 pin SATA connector (signal and power)
Support SATA 3 Revision 3.2
Transparent to the operating system and don’t need driver
Additional it’s include a bracket for install on the backside from the PC
Packaging contents:EX-3608, 4x screw for fix the 2.5” frame, Assembly Guide
EX-48010-2
mini PCIe USB 3.2 Gen 1 with 2 ports (Renesas Chipset)
The EX-48010-2 mini PCIe USB 3.2 Gen 1 (previously called USB 3.0) card provides two super-speed USB 3.0 ports. It is designed to connect two additional USB 1.1, 2.0 or 3.2 Gen 1 end devices to Computersystems or motherboards via the mini PCI-Express bus. It supports USB 1.1 low-speed (1.5Mbps), full-speed (12Mpbs), USB 2.0 high-speed (480Mbps) and USB 3.2 Gen 1 super-speed (5Gbps). The EX-48010-2 is fully PCIe plug-and-play compatible, so it has no conflicts with IRQ and I/O addresses. It is the perfect technology for external storage, digital cameras, webcam, scanners and more. To support power to the external USB 3.2 Gen 1 ports, you don't need an additional power connection from the PC power supply.
Compliant with USB 3.2 Gen 1 and Intel xHCI specification
Supports all USB Compliant Data Transfer Type such as Control/Bulk/Interrupt/Isochronous
Support up to 123 device
Fully PCI Express Gen2 sSpecification compliant
Support “Hot Swapping” and “Plug-and-Play”
Chipset: Renesas D720202
Packaging contents:EX-48010-2, Standard bracket, power cable, 20 pin adapter cable for two USB 3.2 Gen 1 ports, Driver CD, Manual
EX-3649
PCIe (x2) RAID card for each two M.2 NGFF and two mSATA module
With the EX-3649 controller you can expand the computer with two mSATA (Half Size and Full Size) as well as two M.2 NGFF 2280, 2260, 2242 or 2230 modules with B-Key as well as B+M Key. The controller supports RAID 0/1 and JBOD. The EX-3649 requires at least one PCI-Express x2 slot.
PCIe (x2) board for each two M.2 NGFF and mSATA SSD drives
Build in ASM1062R high performance processor
Support RAID 0 / 1 and JBOD and Port Multiplier for two different drives
Supports M.2 NGFF type 22110, 2280, 2260 and 2242 plated-hole mSATA Half Size and Full Size
Supports PCIe specification Rev. 2.0
4A maximum output current
Short circuit protection as Thermal shutdown protection
Packaging contents:EX-3649, Screws for fix M.2 or mSATA moules, Assembly Guide
EX-3676
USB 3.2 Gen 1 C-connector for M.2 or mSATA SSD & SATA
USB 3.2 C-connector for M.2 or mSATA SSD & SATA Adapter (M.2 or mSATA SSD alternative)
Build in ASM1351 USB3.1high performance processor
Build in SATA 22pin Female connector
Build in Mini PCI-e Female connector
Build in M.2 NGFF Female connector
PWM synchronous buck converter Power IC
3A maximum output current
Short circuit protection
Thermal shutdown protection
ESD HBM (Human Body Mode)/2KV
D1 Red LED on indicates SSD Power ready
D2 Red LED Blinking indicates SSD active status
Notice:M.2 SSD or mSATA SSD, only one can work, M.2 SSD would be priority
