EX-61004
Serial Device Server 4x RS232/422/485, incl. power supply
The EX-61004 is a multiprotocol RS-232/422/485 serial device server for integrating RS-232/422/485 serial devices, such as barcode scanners, weighing systems and payment terminals, into an IP-based Ethernet network. The serial devices are connected to the network and are available for sharing on the subnet and the Internet. Extensive network protocols such as TCP Server, TCP Client, UDP, VCOM, Remote Pair Master Slave, Modbus Server, Modbus Client and SNMP are supported. In addition, serial devices with remote pair master-slave mode can communicate with each other via peer-to-peer mode without the need for an intermediate PC or conversion software. With the Virtual COM (VCOM) software available for download, a perfectly migrated virtual serial port can be created on Windows computers for each serial device.
Interface RS-232V.24/422/485 with 4 ports
Interface and operation mode can be defined individually for each port
Data bits: 5, 6, 7, 8 / Stop bits: 1, 2
Parity: None, Even, Odd
Signals:
RS-232: TXD, RXD, RTS, CTS, and GND
RS-422: TXD+, TCD-, RXD+ RXD-, GND
RS-485 2 wire: Data+, Data-, GND
Operating modes:
VCOM, MCP, TCP Server, TCP Client, UDP, Remote Pair mode, Modbus TCP Server, Modbus TCP Client, MQTT
Point to point connection, no software needed
Virtual-COM software (download)
Robust metal housing
Delivery contents:EX-61004, 4x cable adapter RJ45-DB9, power supply, wall mounting bracket, quick start guide
EX-6111-2POE
Ethernet PoE to 1x RS-232 port, incl. 5V/4A power supply
The EX-6111-2PoE is a multi-protocol RS-232 serial Device Server designed to connect a RS-232 serial device, including point-of-sale systems, barcode readers, sensors, meters, weighing systems, CNC controllers and PLCs, to an IP-based Ethernet network. The serial device is connected via Ethernet and available for sharing on the subnet and Internet. Remote configuration is done via extensive network protocols such as TCP server, TCP client, UDP, VCOM or serial Telnet/RFC2217. To ensure backward compatibility with legacy serial devices running existing COM port application software, the EX-6111-2PoE provides a virtual COM port (VCOM) that perfectly migrates your serial application without modifying the software. The EX-6111-2PoE supports Power over Ethernet and can be powered directly from a PoE-compliant power supply unit (PSE) via the Ethernet cable. In addition, serial devices can communicate with each other in peer-to-peer mode without the need for an intermediate PC or conversion software.
Interface: RS-232 V.24
15KV ESD Surge Protection for all serial signal
Data Bits: 5, 6, 7, 8 / Parity: None, Even, Odd, Mark, Space
Fully IEEE 802.3af compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W
RS-232 Signal:
TXD, RXD, RTS, CTS, DTR, DSR, DCD und GND
Ethernet Protocol:
TCP Server, TCP Client, UPD, VCOM, Serial Telnet/RFC2217
Direct connection with Socket Port
Point to point connection, don’t need any software
Virtual COM Software for download
Voltage +5V configurable on pin 9
Rugged Metal Case with Wallmount and DIN-Rail Kit
Delivery contents:EX-6111-2PoE, Power Supply 5V/4A, DIN-Rail Kit, Wallmount kit, Manual
Tip
EX-6164
Ethernet to 4x RS-232 serial, only for Windows operating system
The EX-6164 is a multiprotocol serial-to-Ethernet converter designed to connect RS-232 serial devices such as point-of-sale systems, barcode readers, sensors, gauges, weighing systems, CNC controllers, and PLCs to an IP-based Ethernet network.The converter acts as a “remote USB to serial converter” over Ethernet. With its Windows-based configuration GUI and virtual USB COM drivers, the system can instantly add fully functional serial ports over Ethernet from anywhere.With Ethernet being the most popular and flexible connection in this modern industry, the serial device converter, with its complete software and support for a wide range of selectable models, offers an ideal solution for adding serial devices and increasing the value of your applications.
Interface: RS-232 V.24
15KV ESD Surge Protection for all serial signals
Data Bits: 5, 6, 7, 8 / Parity: None, Even, Odd, Mark, Space
RS-232 Signal: TXD, RXD, RTS, CTS, DTR, DSR, DCD und GND
Ethernet Interface: IEEE 802.3, IEEE 802.3u
Works only with the Virtual COM Software for Windows
Rugged Metal Case with Wall-Mount and Din-Rail Kit
Packaging contents: EX-6164, Power Supply 12V/3A, Manual
NPORT-5610-16
Serial Device Server 16x RS232
With the NPort 5610-16, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network.
Standard 19-inch rackmount size
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP
SNMP MIB-II for network management
Universal high-voltage range: 100 to 240 VAC
Package contents:NPort 5610-16, rack-mount kit, power cord, quick installation guide
EX-6031
Ethernet Data Gateway to 1x RS-232, metall
The EX-6031 in metal box allows you to connect up to four serial devices via the Ethernet network in the simplest way. So you are no longer limited to a fixed distance, but can control any RS-232 peripheral device over the network. You can easily connect EX-6031 to the network with IP address (UDP, IP, TCP, ICMP, HTTP, DHCP, ARP ping). It is also possible to control the devices via the enclosed and other Virtual COM software. The COM ports are then entered in the device manager. The EX-6031 can be screwed directly to the wall or installed in a 19" rack with the optionally available DIN-Rail Kit (EX-6099). Power is supplied via the included plug-in power supply.
Interface: RS-232 V.24
Data Bits: 7, 8
Parity: none, even, odd
RS-232 Signal: TxD, RxD, GND (Loop RTS, CTS, DTR, DSR, DCD)
Ethernet Protocol: IP, TCP, DHCP
Packaging contents:EX-6031, Power Supply +12V/1A, Driver CD, Manual
NPORT-5410
Serial Device Server 4x RS232, w/o power supply
The NPort 5410 device server provides many useful features for serial-to-Ethernet applications, including an independent operation mode for each serial port, user-friendly LCD panel for easy installation, dual DC power inputs, and adjustable termination and pull high/low resistors.
User-friendly LCD panel for easy installation
Adjustable termination and pull high/low resistors
Socket modes: TCP server, TCP client, UDP
Configure by Telnet, web browser, or Windows utility
SNMP MIB-II for network management
Package contents:NPort 5410, terminal block, wall-mounting kit, quick installation guide
NPORT-5630-16
Serial Device Server 16x RS422/485
With the NPort 5630-16, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network.
Standard 19-inch rackmount size
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP
SNMP MIB-II for network management
Universal high-voltage range: 100 to 240 VAC
Package contents:NPort 5630-16, rack-mount kit, power cord, quick installation guide
NPORT-5150
Serial Device Server 1x RS232/422/485, incl. power supply
The NPort 5150 device server is designed to make serial devices network-ready in an instant. The small size of the server makes it ideal for connecting devices such as card readers and payment terminals to an IP-based Ethernet LAN. Use the NPort 5150 device server to give your PC software direct access to serial devices from anywhere on the network.
Small size for easy installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile operation modes
Easy-to-use Windows utility for configuring multiple device servers
SNMP MIB-II for network management
Configure by Telnet, web browser, or Windows utility
Adjustable pull high/low resistor for RS-485 ports
Package contents:NPort 5150, power supply, quick installation guide
EX-6030
Ethernet to 1x Serial RS-232, Metal box
The EX-6030 in metal housing allows you to connect your serial devices over the network (Ethernet) in the simplest way. You are no longer limited to a fixed distance, but can control any RS-232 peripheral device over the network. You can easily connect EX-6030 to the network with IP address (UDP, IP, TCP, ICMP, HTTP, DHCP, ARP ping). The control is also possible via the enclosed and other Virtual Com Port Software. The COM ports are then entered in the device manager. The EX-6030 can be screwed directly to the wall or installed in a 19" rack with the DIN-Rail Kit.
Interface: RS-232 V.24
Data Bits: 7, 8
Parity: none, even, odd
RS-232 Signal: TxD, RxD, GND (Loop RTS, CTS, DTR, DSR, DCD)
Ethernet Protocol: IP, TCP, DHCP
Chipset: Samsung S3C4510B
Packaging contents:EX-6030, Power Supply +5V / 2A, DIN-Rail Kit, Driver CD, Manual
NPORT-5110
Serial Device Server 1x RS232, incl. power supply
The NPort 5110 device server is designed to make serial devices network-ready in an instant. The small size of the server makes it ideal for connecting devices such as card readers and payment terminals to an IP-based Ethernet LAN. Use the NPort 5110 device server to give your PC software direct access to serial devices from anywhere on the network.
Small size for easy installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile operation modes
Easy-to-use Windows utility for configuring multiple device servers
SNMP MIB-II for network management
Configure by Telnet, web browser, or Windows utility
Package contents:NPort 5110, power supply, quick installation guide
NPORT-5210
Serial Device Server 2x RS232, w/o power supply
The NPort 5210 serial device server is designed to make your industrial serial devices Internet-ready in no time. The compact size makes it the ideal choice for connecting your RS-232 serial devices, such as PLCs, meters, and sensors, to an IP-based Ethernet LAN, making it possible for your software to access serial devices from anywhere over a local LAN or the Internet.
Compact design for easy installation
Socket modes: TCP server, TCP client, UDP
Easy-to-use Windows utility for configuring multiple device servers
SNMP MIB-II for network management
Package contents:NPort 5210, quick installation guide
NPORT-5610-8-DT
Serial Device Server 8x RS232
NPort 5600-8-DT device servers can conveniently and transparently connect 8 serial devices to an Ethernet network, allowing you to network your existing serial devices with only basic configuration. You can both centralize management of your serial devices and distribute management hosts over the network. Since the NPort 5600-8-DT device servers have a smaller form factor compared to 19-inch models, they are a great choice for applications that need additional serial ports, but for which mounting rails are not available.
8 serial ports supporting RS-232
Compact desktop design 10/100M auto-sensing Ethernet
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP, Real COM
SNMP MIB-II for network management
Package contents:NPort 5610-8-DT, power supply, wall-mounting kit, patch cord, quick installation guide
NPORT-5610-8
Serial Device Server 8x RS232
With the NPort 5610-8, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network.
Standard 19-inch rackmount size
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP
SNMP MIB-II for network management
Universal high-voltage range: 100 to 240 VAC
Package contents:NPort 5610-8, rack-mount kit, power cord, quick installation guide
NPORT-5210A
Serial Device Server 2x RS232, incl. power supply
The NPort 5210A device server is designed to make serial devices network-ready in an instant and give your PC software direct access to serial devices from anywhere on the network. The NPort 5210A device server is ultra-lean, ruggedized, and user-friendly, making simple and reliable serial-to-Ethernet solutions possible.
Fast 3-step web-based configuration
Surge protection for serial, Ethernet, and power
COM port grouping and UDP multicast applications
Screw-type power connectors for secure installation
Dual DC power inputs with power jack and terminal block
Versatile TCP and UDP operation modes
Package contents:NPort 5210A, power supply, quick installation guide
NPORT-5150A
Serial Device Server 1x RS232, incl. power supply
The NPort 5150A device server is designed to make serial devices network-ready in an instant and give your PC software direct access to serial devices from anywhere on the network. The NPort 5150A device server is ultra-lean, ruggedized, and user-friendly, making simple and reliable serial-to-Ethernet solutions possible.
Power consumption of only 1 W
Fast 3-step web-based configuration
Surge protection for serial, Ethernet, and power
COM port grouping and UDP multicast applications
Screw-type power connectors for secure installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile TCP and UDP operation modes
Connects up to 8 TCP hosts
Package contents:NPort 5150A, power supply, quick installation guide
NPORT-6150
Secure Terminal Server 1x RS232/422/485, incl. power supply
The NPort 6150 device server use the SSL and SSH protocols to transmit encrypted serial data over Ethernet. The NPort 6150’s 3-in-1 serial port supports RS-232, RS-422, and RS-485, with the interface selected from an easy-to-access configuration menu.
Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal, and Reverse Terminal
Supports non standard baudrates with high precision
Enhanced remote configuration with HTTPS and SSH
Port buffers for storing serial data when the Ethernet is offline
Supports IPv6
Generic serial commands supported in Command-by-Command mode
Security features based on IEC 62443
Package contents:NPort 6150, power supply, quick installation guide
NPORT-5110A
Serial Device Server 1x RS232, incl. power supply
The NPort 5110A device server is designed to make serial devices network-ready in an instant and give your PC software direct access to serial devices from anywhere on the network. The NPort 5110A device server is ultra-lean, ruggedized, and user-friendly, making simple and reliable serial-to-Ethernet solutions possible.
Power consumption of only 1 W
Fast 3-step web-based configuration
Surge protection for serial, Ethernet, and power
COM port grouping and UDP multicast applications
Screw-type power connectors for secure installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile TCP and UDP operation modes
Connects up to 8 TCP hosts
Package contents:NPort 5110A, power supply, quick installation guide
NPORT-5450
Serial Device Server 4x RS232/422/485, w/o power supply
The NPort 5450 device server provides many useful features for serial-to-Ethernet applications, including an independent operation mode for each serial port, user-friendly LCD panel for easy installation, dual DC power inputs, and adjustable termination and pull high/low resistors.
User-friendly LCD panel for easy installation
Adjustable termination and pull high/low resistors
Socket modes: TCP server, TCP client, UDP
Configure by Telnet, web browser, or Windows utility
SNMP MIB-II for network management
NPORT-5450-AD
Serial Device Server 4x RS232/422/485, incl. power supply
The NPort 5450 device server provides many useful features for serial-to-Ethernet applications, including an independent operation mode for each serial port, user-friendly LCD panel for easy installation, dual DC power inputs, and adjustable termination and pull high/low resistors.
User-friendly LCD panel for easy installation
Adjustable termination and pull high/low resistors
Socket modes: TCP server, TCP client, UDP
Configure by Telnet, web browser, or Windows utility
SNMP MIB-II for network management
NPORT-5630-8
Serial Device Server 8x RS422/485
With the NPort 5630-8, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network.
Standard 19-inch rackmount size
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP
SNMP MIB-II for network management
Universal high-voltage range: 100 to 240 VAC
Package contents:NPort 5630-8, rack-mount kit, power cord, quick installation guide
NPORT-5250A
Serial Device Server 2x RS232/422/485, incl. power supply
The NPort 5250A device server is designed to make serial devices network-ready in an instant and give your PC software direct access to serial devices from anywhere on the network. The NPort 5250A device server is ultra-lean, ruggedized, and user-friendly, making simple and reliable serial-to-Ethernet solutions possible.
Fast 3-step web-based configuration
Surge protection for serial, Ethernet, and power
COM port grouping and UDP multicast applications
Screw-type power connectors for secure installation
Dual DC power inputs with power jack and terminal block
Versatile TCP and UDP operation modes
Package contents:NPort 5250A, power supply, quick installation guide
NPORT-6650-16
Secure Terminal Server 16x RS232/422/485
The NPort 6650-16 is a terminal server that uses the SSL and SSH protocols to transmit encrypted serial data over Ethernet. The Ethernet port can be configured for a normal or secure TCP/IP connection. The NPort 6650-16 secure device server is the right choice for applications that use large numbers of serial devices packed into a small space. Security breaches are intolerable and the NPort 6650-16 ensures data transmission integrity with support for DES, 3DES, and AES encryption algorithms.
LCD panel for easy IP address configuration
Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal, and Reverse Terminal
Non standard baudrates supported with high precision
Port buffers for storing serial data when the Ethernet is offline
Supports IPv6
Generic serial commands supported in Command-by-Command mode
Security features based on IEC 62443
NPORT-6450
Secure Terminal Server 4x RS232, incl. power supply
The NPort 6450 is a terminal server that uses the SSL and SSH protocols to transmit encrypted serial data over Ethernet. The Ethernet port can be configured for a normal or secure TCP/IP connection. The NPort 6450 secure device server is the right choice for applications that use large numbers of serial devices packed into a small space. Security breaches are intolerable and the NPort 6450 ensures data transmission integrity with support for DES, 3DES, and AES encryption algorithms.
LCD panel for easy IP address configuration
Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal, and Reverse Terminal
Non standard baudrates supported with high precision
Port buffers for storing serial data when the Ethernet is offline
Supports IPv6
Generic serial commands supported in Command-by-Command mode
Security features based on IEC 62443
Package contents:NPort 6450, power supply, quick installation guide
NPORT-5650-16
Serial Device Server 16x RS232/422/485
With the NPort 5650-16, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network.
Standard 19-inch rackmount size
Easy IP address configuration with LCD panel
Configure by Telnet, web browser, or Windows utility
Socket modes: TCP server, TCP client, UDP
SNMP MIB-II for network management
Universal high-voltage range: 100 to 240 VAC
Package contents:NPort 5650-16, rack-mount kit, power cord, quick installation guide
